| Image |
Description |
Industry Application |
Alternative Part# A |
Alternative Part# B |
|
|
1201-021-01-2
CONN Header 1X02POS 2.54mm STACK Straight Solder single row single-plastic colloid Height 2.5 contact plating Gold flash PPS Black UL94V-0 with Specification A 11.6/B 3.2
|
Data communication,Industrial Control，Others |
|
|
|
|
1202-101-01-2
CONN Header 2X05POS 2.54mm STACK Straight Solder double row single-plastic colloid Height 2.5 contact plating Gold flash PPS Black UL94V-0 with Specification A 11.6/B 3.2
|
Data communication,Industrial Control，New Energy，Others |
|
|
|
|
1204-101-01-2
CONN Header 2X05POS 2.54mm STACK Right Angle Solder double row single-plastic colloid Height 2.5 contact plating Gold flash PPS Black UL94V-0 with Specification A 12.5/B 3.2/C 5.9
|
Data communication,Industrial Control，Others |
|
|
|
|
1208-141-12-1
CONN Header 2X07POS 2.54mm STACK SMT double row single-plastic colloid Height 2.5 contact plating Gold flash LCP Black UL94V-0 with Specification A 9.80/B 5.80/C 7.50 with adsorption cap
|
Data communication,Industrial Control，Others |
|
|
|
|
1344-021-2B-D
3.96mm Wafer Connector 02P Straight male Solder Contact plating Sn PA66 Natural UL94V-0 Specification A 3.7/B 14.6
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
1344-XX3-XX-X
3.96mm Wafer Connector 02,03,06P Straight male Solder Through hole Contact plating Au0.076μm, Sn LCP Natural UL94V-0 with lower plate size 3.3
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
1348-060-DB-N
4.20mm Wafer Connector 2 x 03P Double Row Straight male Solder Contact plating Sn LCP Natural UL94V-0 without positioning column hollow male pin lower plate size 3.5
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
1348-080-FB-K
4.20mm Wafer Connector 2x04P double row Straight male Through hole without positioned column contact plating Sn LCP Black UL94V-0 with specificial PIN hole for the 4,6,8 POS fan connector with hollow male pin and Mylar adsorption lower plate size 3.0
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
1348-084-HB-3
4.20mm Wafer Connector 2x04P double row Right Angle male Solder Through hole contact plating Sn LCP Black UL94V-0 with positioned column and lower plate Size 3.2
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
134810XX
1348 series Wafer Housing Female Pitch 4.2mm 2x02,2x03,2×12POS PA66 Natural,Black UL94V-0 With Plate Type wire terminal Twin propeller structure
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
13481102
1348 series Wafer Housing Female Pitch 4.2mm 2x04POS PA66 Black UL94V-0 With front side latch
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
13483002
Wafer female Terminal match with Pitch 4.2 housing phosphor bronze 1.27~2μm Ni under plated contact area plated with Au 0.76μm Press-wire area SN3~5μm crimping 18/24AWG line
|
Data communication,Industrial Control,New Energy，Others |
|
|
|
|
1402-371-A5-1
CONN D-SUB Standard PCB plug vertical 37POS Press-FIT Contact plating Gold flash Sn PBT Black UL94V-0 without matching hardware/Round hole 3.8
|
Data communication,Industrial Control，Others |
|
|
|
|
1402-372-A5-1
CONN D-SUB Standard PCB plug vertical 37POS Press-FIT contact plating Gold flash Sn PBT Black UL94V-0 European standard no supporting hardware/Round hole 3.8
|
Data communication,Industrial Control，Others |
|
|
|
|
1402-XXA-3X-1
CONN D-SUB Standard PCB Receptacle vertical female 25POS Press-FIT Contact plating Au 0.38μm Sn PBT Black UL94V-0 European standard embedded nut (14025008) and pin length 4.0
|
Data communication,Industrial Control，Others |
|
|
|
|
1406-152-15-1
CONN D-SUB high density PCB Receptacle Right Angle 15POS Solder Contact plating Gold flash Sn PBT Black UL94V-0 with front screw 90120018/ Rear gasket 14085003+ harpoon 14065003
|
Data communication,Industrial Control，New Energy，Others |
|
|
|
|
1406-XX4-XX-X
CONN D-SUB high density PCB Receptacle Right Angle female 15POS Solder Contact plating Au 0.38μm ，Au 0.76μm，Goldflash Sn PBT Blue UL94V-0 with front screw 90120018/ rear gasket 14085003+ Harpoon 14065010 with shortened type
|
Data communication,Industrial Control，New Energy，Others |
|
|
|
|
1406-XXB-XX-X
CONN D-SUB high density PCB Receptacle Right Angle female 15POS Solder Contact plating Au0.25μmSn，Au0.76μmSn， Goldflash Sn PA9T Blue UL94V-0 Front shell salt spray 24H with front nut 14075003/rear gasket 14085014+harpoon 14083087 ,rear gasket 14085014+ Harpoon 14083087 with ultrashort type pin length 3.0
|
Data communication,Industrial Control，New Energy，Others |
|
|
|
|
1871-261-07-3
CONN High Speed I/O interface Connector 0.8mm 26POS Right Angle SMT contact plating Au 0.38μm Sn LCP Black UL94V-0 with Mylar
|
Others |
|
|
|
|
1872-261-70-G
CONN Mini SAS 0.8mm Pitch External interface Shield shell 26POS 1 x 1 with 0 degree key 24 plated Ni zinc alloy EMI sponge washer
|
Data communication，Others |
|
|
|
|
1874-201-08-3
CONN SPF 0.8mm Pitch 20POS Right Angle SMT Contact plating Au 0.76μm Sn LCP Black UL94V-0
|
Data communication，Others |
TE 1367073-2 |
|
|
|
1878-222-18-3
CONN SATA 1.27mm Receptacle 07+15POS SMT Vertical Colloid height 8.15 Contact Plating Au 0.76μm Sn LCP Black UL94V-0 with latch plate screw hole
|
Data communication，Others |
|
|
|
|
1882-291-28-3
CONN SAS Female Header 29POS Straight Press-Fit Contact Plating Au 0.76μm Sn LCP Black UL94V-0 with positioning column and lower plate size 3.5
|
Data communication，Others |
|
|
